P6.67 Outdoor Waterproof LED D...
$859.00 Original price was: $859.00.$410.00Current price is: $410.00.
P10 3D Outdoor Advertising LED...
$605.00 Original price was: $605.00.$300.00Current price is: $300.00.
Sale
P4 Outdoor LED Display Screen Billboard 960x960mm Die-cast Fixed Installation LED Display Screen-High Brightness
$1,140.00 Original price was: $1,140.00.$480.00Current price is: $480.00.
P4-OC10S-SMD1921-80×40-L960xH960 Brightness:≥6000CD/㎡ Refresh frequency:≥1920Hz Viewing angle:120° Product description: P4 SMD1921 outdoor commercial LED display board, high brightness, high refresh frequency, low attenuation, high reliability, good consistency, non-mosaic phenomenon.
SKU:
P4-Outdoor-10S-SMD1921-80x40-L960xH960
Categories: Outdoor LED Billboard Advertising 960x960
Share:
P4 Outdoor LED Display Screen Billboard 960x960mm Die-cast Fixed Installation LED Display Screen-High Brightness
Notice before order:
1) Parts included : Waterproof steel cabinet, LED modules, power supplies, NOVASTAR receiving card, power cables and signal cables. It does not include sending card. You can order the sending card by this link: NOVASTAR MSD300 sending card.
2) Buy cabinets of same batch: to avoid brightness&color difference on one single screen, you must buy cabinets of the same batch. That is, you must buy the cabinets for one single screen by one order from us.
3) Shipping: The above price does not include shipping cost. The goods can be shipped by sea, by air, by train or by express. You can get your forwarder to ship the goods for you. If you need us to ship the goods, please talk with our online sales to confirm the shipping details.
4) Tariff: Our price does not include any tariff or duties at the destination, you should do import customs clearance and pay all tariff or duties locally.
P4 Outdoor 960x960mm Die-cast Fixed Installation LED Display Screen-High Brightness Features:
1) Wide viewing angles. Both the horizontal viewing angle and vertical viewing angle can reach 120 degrees.
2) Good color and brightness conformity. The LED chip is sorted by 2.5nm, while the chip brightness
difference is within 10%.
3) Small gaps between modules and perfect screen flatness. The gaps between modules are smaller than 1 mm and screen flatness is less than 1 mm.
4) High Level waterproof level which is suit for outdoor fixed installation.
5)1920HZ refresh rate, 14bit color depth,62,500 pixel/sqm.
6) Easy to move and install .
P4 Outdoor 960x960mm Die-cast Fixed Installation LED Display Screen-High Brightness Applications:
Exterior advertising LED display, exterior rental LED display
P4 Outdoor LED Display Screen Billboard 960x960mm Die-cast Fixed Installation LED Display Screen-High Brightness Parameter:
| Module Parameter | |
| Pixel Pitch | 4mm |
| Pixel Configuration | SMD1921 |
| Density | 62,500 pixels/㎡ |
| Module Resolution | 80pixel(L) * 40pixel(H) |
| Module Dimension | 320mm(L) * 160mm(H) * 25mm(D) |
| Driving Mode | Constant current, 1/10 duty |
| Module Mask | Pure black mask—high contrast screen |
| LED Cabinet | |
| Module Quantity in a Cabinet | 3(L) * 6(H) |
| Cabinet Dimension | 960（L）* 960（H）* 144(D)mm |
| Cabinet Resolution | 240(L) * 240(H) |
| Cabinet Material | Die-Cast magnesium alloy |
| Cabinet Weight | ≈25KG |
| Electricity Parameter | |
| Optical Ratings | |
| Brightness | ≥6,000 cd/㎡ |
| Viewing Angle | 120°(Horizontal); 120°(Vertical) |
| Best Viewing Distance | ≥4m |
| Gray Grade | 14 bits |
| Display Color | 4.4 trillion Colors |
| Brightness Adjustment | 100 grades by software or automatically by sensor |
| Operation Power | AC100-240V 50-60Hz Switchable |
| Max. Power Consumption | 878W/㎡ |
| Avg. Power Consumption | 293W/㎡ |
| Control System | |
| Frame Frequency | ≥60Hz |
| Refresh Frequency | ≥1,920Hz |
| Input Signal | Composite Video, S-video, DVI, HDMI, SDI, HD-SDI |
| Control Distance | 100m(Ethernet cable); |
| 20KM(optical fiber cable) | |
| Support VGA Mode | 800*600, 1024*768, 1280*1024, 1600*1200 |
| Color Temperature | 5000—9300 adjustable |
| Brightness Correction | Pixel by pixel, module by module, cabinet by cabinet |
| Reliability | |
| Working Temperature | -20～+60 ºC |
| Storage Temperature | -30～+70 ºC |
| Working Humidity | 10%～90% RH |
| Lifetime | 100,000 hours |
| MTBF | 5000 hours |
| Continuous Operating Time | ≥72 hours |
| Protection Grade | IP65(front), IP54(rear) |
| Out-of-Control Pixel Rate | ≤0.01% |
