Sale

P0.4 P0.6 P0.7 P0.9 P1.2 P1.5 P1.8 P1.9 P2 P2.5 Small Pixel Pitch LED Wall Screen COB LED Display Module 320×160

Original price was: $10.00.Current price is: $9.90.

or
SKU: COB GOB SMD LED DISPLAY MODULE Categories: , ,

Share:

P0.4 P0.6 P0.7 P0.9 P1.2 P1.5 P1.8 P1.9 P2 P2.5 Small Pixel Pitch LED Wall Screen COB LED Display Module 320×160

Indoor LED Display Module 320x160mm Series
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P1.25mm SMD1010 320*160 256*128 1/64 3840 800
P1.53mm SMD1010 320*160 208*104 1/52 3840 800
P1.86mm SMD1515 320*160 172*86 1/43 3840 1000
P2mm SMD1515 320*160 160*80 1/40 3840 1000
P2.5mm SMD2020 320*160 128*64 1/32 3840 1000
P3.076mm SMD2020 320*160 104*52 1/26 3840 1000
P4mm SMD2020 320*160 80*40 1/20 3840 1000
Cable Connection Indoor LED Module 250x250mm Series
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P1.56mm(GOB) SMD1212 250*250 160*160 1/40 3840-7680 800
P1.95mm(GOB) SMD1515 250*250 128*128 1/32 3840-7680 1000
P2.6mm(GOB) SMD1515 250*250 96*96 1/32 3840-7680 1000
P2.97mm SMD2020 250*250 84*84 1/28 3840-7680 1000
P3.91mm SMD2020 250*250 64*64 1/16 3840-7680 1000
Hub Connection Indoor LED Module 250x250mm Series
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P1.56mm(GOB) SMD1212 250*250 160*160 1/40 3840-7680 800
P1.95mm(GOB) SMD1515 250*250 128*128 1/32 3840-7680 1000
P2.6mm(GOB) SMD1515 250*250 96*96 1/32 3840-7680 1000
P2.97mm SMD2020 250*250 84*84 1/28 3840-7680 1000
P3.91mm SMD2020 250*250 64*64 1/16 3840-7680 1000
Hub Connection Indoor Flexible LED Module 250x250mm Series
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P1.95mm(GOB) SMD1515 250*250 128*128 1/32 3840 1000
P2.6mm(GOB) SMD1515 250*250 96*96 1/32 3840 1000
P2.97mm SMD2020 250*250 84*84 1/28 3840 1000
P3.91mm SMD2020 250*250 64*64 1/16 3840 1000
Other Series Hub Connection Indoor LED Module
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P0.93mm MiniLED 300*168.75 320*180 1/60 3840 800
P1.25mm SMD1010 300*168.75 240*135 1/60 3840 800
P1.56mm SMD1010 300*168.75 192*108 1/64 3840 800
P1.87mm SMD1515 300*168.75 160*90 1/45 3840 800
P1.25mm SMD1010 320*180 256*144 1/60 3840 800
P1.53mm SMD1010 320*180 208*116 1/60 3840 800
P1.86mm SMD1010 320*180 172*96 1/64 3840 800
P1.25mm SMD1010 320*160 256*128 1/64 3840 800
P1.53mm SMD1010 320*160 208*104 1/52 3840 800
P1.86mm SMD1515 320*160 172*86 1/43 3840 1000
P2mm SMD1515 320*160 160*80 1/40 3840 1000
P2.5mm SMD2020 320*160 128*64 1/32 3840 1000
Other Series Indoor LED Display Modules
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P2mm SMD1515 256*128 128*64 1/32 3840 1000
P2.5mm SMD2020 160*160 64*64 1/32 3840 1000
P3mm SMD2020 192*192 64*64 1/32 3840 1000
P4mm SMD2020 256*128 64*32 1/16 3840 1000
P4mm SMD2020 256*256 64*64 1/32 3840 1000
COB LED Display Module 320x160mm Series
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate (Hz) Brightness (Nits)
P1.25mm Flip chip COB 320*160 256*128 1/64 3840 1000
P1.53mm Flip chip COB 320*160 208*104 1/52 3840 1000
P1.86mm Flip chip COB 320*160 172*86 1/43 3840 1000
COB LED Display Module 150×168.75mm Series
Pixel Pitch LED Type Module Size (MM) Module Resolution Driving Mode Refresh Rate (Hz) Brightness (Nits)
P0.62mm Flip chip COB 150*168.75 242*272 1/64 3840 800
P0.78mm Flip chip COB 150*168.75 192*216 1/64 3840 800
P0.93mm Flip chip COB 150*168.75 160*180 1/60 3840 800
P1.25mm Flip chip COB 150*168.75 120*135 1/60 3840 800
P1.56mm Flip chip COB 150*168.75 96*108 1/54 3840 800
P1.87mm Flip chip COB 150*168.75 80*90 1/45 3840 800
GOB LED Screen Panel 320x160mm Series
Pixel Pitch LED Type Module Size (MM) Module Resolution Driving Mode Refresh Rate (Hz) Brightness (Nits)
P1.25mm SMD1010 (Black LED) 320*160 256*128 1/32 3840 800
P1.53mm SMD1010 (Black LED) 320*160 208*104 1/26 3840 800
P1.86mm SMD1515(Black LED) 320*160 172*86 1/43 3840 1000
P2mm SMD1515(Black LED) 320*160 160*80 1/40 3840 1000
P2.5mm SMD2020(Black LED) 320*160 128*64 1/32 1920 / 3840 1000
P3.076mm SMD2020(Black LED) 320*160 104*52 1/26 1920 / 3840 1000
GOB LED Display Panel 250x250mm Series
Pixel Pitch LED Type Module Size (MM) Module Resolution Driving Mode Refresh Rate (Hz) Brightness (Nits)
P1.56mm SMD1212(Black LED) 250*250 160*160 1/40 3840 800
P1.95mm SMD1515(Black LED) 250*250 128*128 1/32 3840 1000
P2.5mm SMD1515(Black LED) 250*250 100*100 1/25 3840 1000
P2.6mm SMD1515(Black LED) 250*250 96*96 1/32 3840 1000
GOB LED Screen Module
Pixel Pitch LED Type Module Size (MM) Module Resolution Driving Mode Refresh Rate (Hz) Brightness (Nits)
P2mm SMD1515(Black LED) 256*128 128*64 1/32 1920 / 3840 1000
P2.5mm SMD2020(Black LED) 160*160 64*64 1/32 1920 / 3840 1000
P3mm SMD2020(Black LED) 192*192 64*64 1/32 1920 / 3840 1000
Outdoor LED Display Module 320x160mm Series
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P1.25mm SMD1010 320*160 256*128 1/64 3840 4000
P1.53mm SMD1010 320*160 208*104 1/52 3840 4000
P1.86mm SMD1010 320*160 172*86 1/29 3840 4000
P2mm SMD1010 320*160 160*80 1/20 3840 4000
P2.5mm SMD1415 320*160 128*64 1/16 3840 5000
P3.076mm SMD1415 320*160 104*52 1/13 3840 5000
P4mm SMD1921 320*160 80*40 1/10 3840 5500
P5mm SMD2727 320*160 64*32 1/8 3840 6000
P5mm SMD1921 320*160 64*32 1/8 3840 5500
P6.67mm SMD3535 320*160 48*24 1/6 3840 6500
P8mm SMD3535 320*160 40*20 1/5 3840 6500
P10mm SMD3535 320*160 32*16 1/2 3840 7000
P10mm DIP346 1R1G1B 320*160 32*16 1/4 3840 12000
Flexible Mask Outdoor LED Display Module 320×160
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P5mm SMD1921 320*160 64*32 1/8 3840 6000
P5mm SMD2727 320*160 64*32 1/8 3840 6000
P6.67mm SMD3535 320*160 48*24 1/6 3840 6000
P8mm SMD3535 320*160 40*20 1/5 3840 6000
P10mm SMD3535 320*160 32*16 1/2 3840 6500
Outdoor LED Display Module 80x160mm Series
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P4mm SMD1921 80*160 20*40 1/10 3840 5500
P5mm SMD1921 80*160 16*32 1/8 3840 5500
P6.67mm SMD3535 80*160 12*24 1/6 3840 5500
P8mm SMD3535 80*160 10*20 1/5 3840 5500
P10mm SMD3535 80*160 8*16 1/2 3840 5500
Cable Connection Outdoor LED Display Module 250×250
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P2.6mm SMD1415 250*250 96*96 1/24 3840-7680 4800
P2.97mm SMD1415 250*250 84*84 1/21 3840-7680 4800
P3.91mm SMD1921 250*250 64*64 1/16 3840-7680 5000
P3.91mm SMD1921 250*250 64*64 1/8 3840-7680 5500
P3.91mm SMD1921(black) 250*250 64*64 1/8 3840-7680 6000
Hub Connection Outdoor LED Display Module 250×250
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P2.6mm SMD1415 250*250 96*96 1/24 3840-7680 4800
P2.97mm SMD1415 250*250 84*84 1/21 3840-7680 4800
P3.91mm SMD1921 250*250 64*64 1/16 3840-7680 5000
P3.91mm SMD1921 250*250 64*64 1/8 3840-7680 5500
P3.91mm SMD1921(black) 250*250 64*64 1/8 3840-7680 6000
Flexible Hub Connection Outdoor LED Display Module 250×250
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P2.6mm SMD1415 250*250 96*96 1/24 3840 4800
P2.97mm SMD1415 250*250 84*84 1/21 3840 4800
P3.91mm SMD1921 250*250 64*64 1/16 3840 5500
Hub Connection Outdoor LED Display Module 288×288
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P3.79mm SMD1921 288*288 76*76 1/19 3840-7680 5000
P4.81mm SMD1921 288*288 60*60 1/10 3840-7680 5000
Outdoor LED Screen Panel 192x192mm
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P3mm SMD1415 192*192 64*64 1/16 3840 5500
P6mm SMD2727 192*192 32*32 1/6 3840 5500
P6mm SMD3535 192*192 32*32 1/8 3840 6000
Other Series Outdoor LED Screen Module
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P2.5mm SMD1415 160*160 64*64 1/16 3840 5000
P4mm SMD1921 256*128 64*32 1/8 3840 6000
P8mm SMD3535 256*128 32*16 1/4 3840 6000
P10mm DIP346 1R1G1B 160*160 16*16 1/4 1920 10000
P16mm DIP346 1R1G1B 256*256 16*16 1/1 1920 10000
Energy-saving Outdoor LED Display Module 320×160
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P2.5mm SMD1415 320*160 128*64 1/16 3840 5000
P3.076mm SMD1415 320*160 104*52 1/13 3840 5000
P4mm SMD1921 320*160 80*40 1/10 3840 5500
P5mm SMD1921 320*160 64*32 1/8 3840 5500
P6.67mm SMD3535 320*160 48*24 1/6 3840 6000
P8mm SMD3535 320*160 40*20 1/5 3840 6500
P10mm SMD3535 320*160 32*16 1/2 3840 7000
Energy-saving Outdoor LED Display Module 80x160mm
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P4mm SMD1921 80*160 20*40 1/10 3840 6000
P5mm SMD1921 80*160 16*32 1/8 3840 6000
P6.67mm SMD3535 80*160 12*24 1/6 3840 6500
P8mm SMD3535 80*160 10*20 1/5 3840 6500
P10mm SMD3535 80*160 8*16 1/2 3840 7500
Flexible Soft LED Screen Module 320x160mm Series
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P1.25mm SMD1010 320*160 256*128 1/64 3840 800
P1.29mm SMD1010 320*160 248*124 1/62 3840 800
P1.53mm SMD1212 320*160 208*104 1/52 3840 800
P1.56mm SMD1212 320*160 204*102 1/51 3840 800
P1.86mm SMD1212 320*160 172*86 1/43 3840 800
P2.mm SMD1515 320*160 160*80 1/40 3840 1000
P2.5mm SMD1515 320*160 128*64 1/32 3840 1000
P3.076mm SMD2020 320*160 104*52 1/26 3840 1000
P4mm SMD2020 320*160 80*40 1/20 3840 1000
P5mm SMD2020 320*160 64*32 1/16 3840 1000
Flexible Soft LED LED Display Module 240x120mm Series
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P0.9mm COB 240*120 256*128 1/64 3840 800
P0.9mm IMD-M09 240*120 256*128 1/64 3840 800
P1.25mm SMD1010 240*120 192*96 1/48 3840 800
P1.579mm SMD1212 240*120 152*76 1/38 3840 800
P1.875mm SMD1515 240*120 128*64 1/32 3840 1000
P2.mm SMD1515 240*120 120*60 1/30 3840 1000
P2.5mm SMD1515 240*120 96*48 1/24 3840 1000
P3mm SMD2020 240*120 80*40 1/20 3840 1000
P4mm SMD2020 240*120 60*30 1/15 3840 1000
Outdoor Flexible Soft LED Screen Module 320x160mm Series
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P2.5mm SMD1415 320*160 128*64 1/16 3840 4500
P3.076mm SMD1415 320*160 104*52 1/14 3840 4500
P4mm SMD1921 320*160 80*40 1/10 3840 5000
Flexible Soft LED Display Module 256x128mm & 200x150mm
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P1.56 SMD1212 200*150 128*96 1/48 3840 800
P2mm SMD1515 256*128 128*64 1/32 3840 1000
P4mm SMD2020 256*128 64*32 1/16 3840 1000
Flexible Soft LED Display Module 250x250mm Series
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P1.56mm SMD1212 250*250 160*160 1/40 3840 800
P1.95mm SMD1515 250*250 128*128 1/32 3840 1000
P2.6mm SMD1515 250*250 96*96 1/32 3840 1000
Flexible Soft LED Display Module 300×168.75mm Series
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P1.2mm SMD1010 300*168.75 240*135 1/45 3840 800
P1.5mm SMD1212 300*168.75 192*108 1/54 3840 800
P1.8mm SMD1515 300*168.75 160*90 1/45 3840 1000
P2.3mm SMD1515 300*168.75 128*72 1/36 3840 1000
Dual Service (Frontal & Rear) Outdoor LED Module 320×320
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P4mm SMD1921 320*320 80*80 1/10 3840 5500
P5mm SMD1921 320*320 64*64 1/8 3840 5500
P5.33mm SMD1921 320*320 60*60 1/8 3840 5500
P6.67mm SMD2727 320*320 48*48 1/6 3840 6000
P8mm SMD3535 320*320 40*40 1/5 3840 6500
P10mm SMD3535 320*320 32*32 1/2 3840 7000
P10mm DIP346 320*320 32*32 1/4 3840 12000
P16mm DIP346 320*320 20*20 1/1 3840 10000
Dual Service (Frontal & Rear) Outdoor LED Module 250×250
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P3.12mm SMD1415 250*250 80*80 1/10 3840 6500
P3.91mm SMD1921 250*250 64*64 1/8 3840 6000
P4.81mm SMD1921 250*250 52*52 1/6 3840 5500
P5.95mm SMD2727 250*250 42*42 1/7 3840 6000
P6.94mm SMD2727 250*250 36*36 1/6 3840 6000
P8.33mm SMD3535 250*250 30*30 1/5 3840 6500
P10.41mm SMD3535 250*250 24*24 1/2 3840 7000
Dual Service (Frontal & Rear) Outdoor LED Module 320×160
Pixel Pitch LED Type Module Size（MM） Module Resolution Driving Mode Refresh Rate(Hz) Brightness(Nits)
P3.33mm SMD1415 320*160 96*48 1/12 3840 5500
P4mm SMD1921 320*160 80*40 1/10 3840 5500
P5mm SMD1921 320*160 64*32 1/8 3840 5500
P6.67mm SMD2727 320*160 48*24 1/6 3840 5500
P8mm SMD2727 320*160 40*20 1/5 3840 6000
P10mm SMD2727 320*160 32*16 1/2 3840 6500

Reviews

There are no reviews yet.

Be the first to review “P0.4 P0.6 P0.7 P0.9 P1.2 P1.5 P1.8 P1.9 P2 P2.5 Small Pixel Pitch LED Wall Screen COB LED Display Module 320×160”

Your email address will not be published. Required fields are marked

You have to be logged in to be able to add photos to your review.

Related products

128×256 LED Display Screen P4 SMD LED Module GOB led display supplier

Original price was: $5.50.Current price is: $4.50.

Indoor LED Display 256×128 P2 LED Module Panel 1/32 Scan COB led display board

Original price was: $13.40.Current price is: $9.50.

P5 Indoor SMD LED Display Board 160mmx160mm 1/16 Scan LED Display Module

Original price was: $14.50.Current price is: $14.00.

P1.25 LED Display Panel LED Module 320mmx160mm 1/64 Scan GOB COB led display module

Original price was: $36.00.Current price is: $32.10.

P1.538 LED Screen 320×160 COB GOB SMD RGB LED Display Module 1/52 Scan led screen factory

$28.50
Home
Shop
Contact us
More
More

You may add any content here from XStore Control Panel->Sales booster->Request a quote->Ask a question notification

At sem a enim eu vulputate nullam convallis Iaculis vitae odio faucibus adipiscing urna.

Ask an expert
New Subscription

Why LEEMAN

Help Center

Hot Products

P0.4 P0.6 P0.7 P0.9 P1.2 P1.5 P1.8 P1.9 P2 P2.5 Small Pixel Pitch LED Wall Screen COB LED Display Module 320×160
Original price was: $10.00.Current price is: $9.90.

© 1994-2026 LeemanLEDScreen. All Rights Reserved
