IP67 Common Cathode Outdoor Aluminum LED Display Outdoor P2.5 LED Display 960×960 LED Wall Video Screen
$524.53 Original price was: $524.53.$479.00Current price is: $479.00.
Model: P2.5 Outdoor Video LED Display 960×960
Brightness:≥5000CD/㎡
Refresh frequency:≥3840Hz
Viewing angle:120°
Product description: P2.5 SMD1415 indoor commercial LED display board, high brightness, high refresh frequency, low attenuation, high reliability, good consistency, non-mosaic phenomenon.
SKU:
LEEMAN-P2.5-outdoor-SMD1415-LED-SCREEN-L960xH960
Categories: Outdoor LED Video Panels 960x960, P2.5 Rental LED Display 960x960
Share:
Outdoor P2.5 LED Display 960×960 Outdoor P2.5 LED Display Module LED Wall Video Screen For Sale
Notice before order:
1) Parts included : High-quality steel cabinets, LED modules, power supplies, NOVASTAR receiving card, power cables and signal cables. It does not include sending card. You can order the sending card by this link: NOVASTAR MSD300 sending card.
2) Buy cabinets of same batch: to avoid brightness&color difference on one single screen, you must buy cabinets of the same batch. That is, you must buy the cabinets for one single screen by one order from us.
3) Shipping: The above price does not include shipping cost. The goods can be shipped by sea, by air, by train or by express. You can get your forwarder to ship the goods for you. If you need us to ship the goods, please talk with our online sales to confirm the shipping details.
4) Tariff: Our price does not include any tariff or duties at the destination, you should do import customs clearance and pay all tariff or duties locally.
P2.5 outdoor 960x960mm Die-cast Fixed Installation LED Video Wall Features:
1) Wide viewing angles. Both the horizontal viewing angle and vertical viewing angle can reach 120 degrees.
2) Good color and brightness conformity. The LED chip is sorted by 2.5nm, while the chip brightness difference is within 10%.
3) Small gaps between modules and perfect screen flatness. The gaps between modules are smaller than 1 mm and screen flatness is less than 1 mm.
4) Different cabinet styles are available, such as fixed installation style, rental hanging style, ultra-thin style。
P2.5mm 160x160mm Outdoor LED Display Module LED Video Wall Applications:
indoor Rental LED Screen
Indoor commercial LED screen
Indoor stage background LED curtain
Outdoor P2.5 LED Display 960×960 LED Wall Video Screen For Sale Pararmeter:
| Item | Technical Parameters |
| Nationstar REESTAR SMD GOB LED Chip Parameters | |
| Item Name | LED Type |
| Red LED | SMD1415 |
| Green LED | SMD1415 |
| Blue LED | SMD1415 |
| LEEMAN LED DISPLAY Module Specification | |
| Pixel Pitch | LeemanLED-P2.5mm |
| Pixels Density | 160,000 pixels/m2 |
| LED Configuration | Nationstar SMD RGB 3in1 |
| Package Mode | GOB SMD1415 |
| Module Size | 160mm X 160mm and 320mm x 160mm |
| Module Resolution | 64 x 64 pixels and 128 x 64 pixels |
| Module Pixles | 4096 pixels and 8192 pixels |
| Max Power Consumpion | 45W |
| Module Thickness | 25mm |
| PCB Board | 4 Layer PCB Board With 1.6mm |
| Driving IC | MBI5153 or ICN2163 |
| Drive Type | Constant drive |
| Driving Method Scan Mode | 1/16 scan (160×160) or 1/32 scan (320×160) |
| Port Interface Type | HUB75 |
| Module Input Voltage | DC5V |
| Brightness of White Balance | ≥5500cd/㎡ |
| LEEMAN LED DISPLAY Cabinet Specification | |
| Cabinet Size(W X H X D) | 480mm x 480mm x 65mm and 640mm x 640mm x 65mm |
| Cabinet Resolution(dot) | 192 x 192 pixels and 256 x 256 pixels |
| Module Quanity (pcs) | 9pcs / 8pcs |
| Cabinet Pixels | 36864 pixels |
| Pixel Density | 160000 pixels/m2 |
| Cabinet Materials | Die Casting Aluminum Cabinet for rental purpose |
| Cabinet Weight | 7kg per cabinet |
| Whole LEEMAN LED DISPLAY Screen Specification | |
| Screen Brightness | ≥5500cd/m2 |
| Driving Method | 1/32 scan |
| Best Viewing Distance | 2m – 50m |
| Max. Power Consumption | 600W/m2 |
| Average Power Consumption | 350W/m2 |
| Gray Level | 8bits input, 4096 levels(212) |
| Display Color | 256M |
| Frame Frequency | ≥60Hz |
| Refresh Frequency | ≥3840Hz – 6420Hz |
| Uninterrupted Working Hours | ≥72 hours |
| Screen Life-span | ≥100,000 hours |
| MTBF | ≥10,000 hours |
| Discrete Blind Spot Rate | <1/20000 |
| Continuous Blind Spot Rate | None |
| Waterproof Level | IP65 |
| Blind Spot Rate | <1/10000 |
| Protective Scale | For Outdoor and indoor use |
| Screen Plainness | <±1mm |
| Power Supply Mode | AC220±10% 50Hz / AC110±10% 60Hz |
| Environment Temperature & Humidity | Temperature:-35 Celsius~ 60 Celsius |
| Humidity:10%~90% RH | |
| Control Mode | Synchronous display with control PC by DVI |
| Control System | DVI video card full color control card fiber system(optional) |
| Display Content | HDMI, VGA, Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc. |
| Interface | Standard Ethernet |
| Transmission Distance | Multi mode fiber <500m, single mode fiber <30km,internet cable <100m |
| Control System | Linsn LED, Novastar LED, Colorlight LED or as you required |
| Power Supply Brand | G-energy, MeanWell, Chuanglian or as you required |
| Certificate | UL, EMC, CE, ROHS, FCC |
