P2.5 Spherical LED Display Diameter 1 meter LED Video Sphere Screen

Original price was: $4,800.00.Current price is: $3,683.27.

Free tech guide
2 years warranty
5% Spare Part, Power Supply, Receiver cards included.
Lead time: 15-21 working days.

Certification: UL CUL ETL FCC CE ENEC ROHS LVD EMC VDE E/e Mark SAA EK PSE CSA ISO

SKU: LEEMAN-P2.5-Spherical-LED-Display Categories: Sphere LED Display Ball

Description

Shipping & delivery

P2.5 Spherical LED Display Diameter 1 meter Sphere LED Screen
Application: Indoor Shopping mall, Bar, Club or Stage Use

LED Sphere Display Feature:
* Pitch 2.5mm
* Creative Design
* Easy to maintain
* Indoor Application
* Diameter=0.5meter (Option 1m/2m/3m/4m/5m/6m )

Sphere LED display is becoming very popular in bar, nightclub, show, stadium etc.
Different models of sphere LED displays are available in LEEMANDISPLAY.

Application: Indoor and outdoor designs available
Display color: full color
Pixel pitch: 10mm, 6mm, 4.8mm,4mm, 3mm,2.5mm,2mm, 1.8mm etc
Diameter: 1m, 1.5m, 2m, 3m. 4m, 5m, 6m, 8m, 10m etc

P2.5 Spherical LED Display Diameter 1meter

Specification:
Parameter	Unit	Value
Pitch	mm	2.5
Brightness	nits	1000
Color temperature	deg. K	6500
Viewing angle – Horizontal (50% brightness)	deg.	140(-70 ~ 70)
Viewing angle – Vertical (50% brightness)	deg.	140(-70 ~ 70)
Net Weight	kg	25
Diameter	mm	500
Panel area	sq. m.	0.785
Operating temperature range	deg. C	-30 to 60
Structure material		Steel
Ingress protection (front/rear)		IP23
Humidity operating	RH	10% ~ 90%
Pixel type and configuration	R/G/B	3in1 SMD
Dot per sq. meter		250000
LED per sq. meter		250000
Recommended minimum viewing distance	m	1.5
Recommended best viewing distance	m	2~100
Colors		281 trillion
Grey scale (linear)	Levels	65536 levels per color
Brightness control	Levels	100
Contrast ratio		3000:01:00
Processing depth	bit	16
Video frame rate	Hertz	60
Display refresh rate	Hertz	600
Input voltage (nominal)	VAC	110 to 240
Input power frequency	Hertz	50 to 60
Input power (max)	Watts/pc	500
Input power (typical)	Watts/pc	200
Lifetime (50% brightness)	Hours	≥100000
Red wavelength (dominant)	nm	620~625
Green wavelength (dominant)	nm	525~530
Blue wavelength (dominant)	nm	470~475
Multimedia data format		DVI,MPG,AVI,WMV,RM etc.
Controller		NOVA TB2
Data interconnection		UTP Cat 5
Mounting system		Hanging & Stand on ground
Package		PLY wooden case
