Outdoor P16 LED Module 320mmx320mm Brightness 9000nits Dual Service LED Display 960×960

Original price was: $28.70.Current price is: $27.50.

Pixel Pitch: 16mm
Module Size: 320*320mm
Model Pixel: 20*20Pixels
LED Type: DIP 346

Certification: UL CUL ETL FCC CE ENEC ROHS LVD EMC VDE E/e Mark SAA EK PSE CSA ISO

or
SKU: Leeman Outdoor P16 LED Module 320mmx320mm Categories:

Share:

Outdoor P16 LED Module 320mmx320mm Brightness 9000nits Dual Service LED Display 960×960

Outdoor P16mm DIP LED Display Module Size is 320mmx320mm With 20×20 dots.

Attention:

  • We recommend that you buy the same batch led modules at once for the Same LED Display.Because different batches of led modules have different brightness and display colors,even different config files.
  • If you want to build led screen,please buy enough LED Modules and Spare Parts.
  • Tariffs or Duties at the destination not included.If you have questions about Importation to your country,please contact us online sales.

P16 Outdoor DIP 320mmx320mm Dual Service LED Display Module Main Specifications:

Items Parameter
LED Module LEEMAN-P16-Outdoor-20X20-DIP
Resolution 20(W)×20(H)
Pitch 16mm
LED Arrangement DIP346, 1R1G1B
Driver Mode 1/1 Scan
Size 320mm×320mm
Electricity Parameter
Brightness ≥7000cd/m²
View Angle 120 degree (horizontal & vertical)
View Distance 16m-1600m
Gray Scale 12bits input, correction with 16bits
Display Color 16.7M
Brightness Adjustment 100 levels
Operation Power AC100-240V 50-60HZ Switch-able
Maxim Power Consumption 15W
Control System
Correction Scale Level 16bits
Frame Update Frequency 60Hz
Screen Refresh Frequency ≥1960HZ
Gamma Correction -5.0~5.0
Support Input Composite Video, S-Video, DVI, HDMI., SDI, HD_SDI
Control Distance Ethernet cable 100m, optical fiber 5km
Support VGA Mode 800×600,1024×768,1280×1024,1600×1200
Color Temperature 5000-9300 adjustable
Brightness Correction dot by dot, module by module, cabinet by cabinet
Reliability
Working Temperature -20~+60 ºC
Storage Temperature -30~+70 ºC
Working Humidity 10%~90% RH
Lifetime 100,000 hours
MTBF 5000 hours
Continuous Operating Time ≥72 hours
Out-of-Control Pixel Rate ≤0.01%

High Quality LEDs:

High-Quality 1R1G1B LED Display Module are equipped with data cables and power cables and 2 Years Warranty, All Outdoor LED panels with high brightness and color uniformity to ensure the LED display has excellent visual performance.

72+ Hours Aging

72 Hours aging test (white balance aging (2×24 hours) and video aging (24 hours)) to improve the reliability of the outdoor LED display panels.

Front & Rear Maintanence Service:

Dual-mode maintenance (Front & Rear Service) outdoor LED module , saving the maintenance space and being compatible with hard installation conditions.
