ViPlex Novastar VX4 LED Video Processor Leeman LED Controller
$1,090.00 Original price was: $1,090.00.$1,028.00Current price is: $1,028.00.
- Inputs include CVBS×3, VGA×3, DVI×2, HDMI×1 ,DP×1
- HDMI/external audio input
- Loading capacity: 2.3 million pixel
- Certification: UL CUL ETL FCC CE ENEC ROHS LVD EMC VDE E/e Mark SAA EK PSE CSA ISO
Categories: Novastar LED Control Card
Share:
ViPlex Novastar VX4 LED Video Processor Leeman LED Controller Specification
- Seamless high-speed switch and fade-in/ fade-out effect.
- The location and size of PIP can both be adjusted.
- Nova G4 engine
- white balance calibration and color gamut mapping
- point-by-point correction
| ViPlex Novastar VX4 LED Video Processor Leeman LED Controller Machine Specification | |
| Input power | AC 100-240V~, Hz 50/60 |
| Power consumption | 25W |
| Working temperature | -20℃ ~60℃ |
| Size | 483.6×275.1×51.5(mm) |
| Weight | 2.55 Kg |
| Input indicators | |||
| Port | Amount | Resolution specifications | |
| VX4 | VX4S | ||
| VGA | 3 | 2 | VESA standards, maximum support 1920×1200@60 Hz Input |
| DVI | 2 | 1 | VESA standard (support 1080 i input), support HDCP |
| CVBS | 3 | 2 | PAL/NTSC |
| HDMI | 1 | 1 | EIA/CEA-861 standards, meet HDMI-1.3 standards, support HDCP |
| DP | 1 | 1 | VESA standards |
| SDI | No | 1 | 480 i 、576i 、720P 、1080i/P |
| Output indicators | |||
| Port | Amount | Resolution specifications | |
| VX4 | VX4S | ||
| DVILOOP | 1 | 1 | DVI input loop out, consistent with DVI input |
| DVI | 2 | 2 | Pre-monitoring output interface |
| SDI LOOP | No | 1 | SDI input loop out, consistent with SDI input |
| LED OUT | 4 | 4 | Four channels Gigabit network port output, only network port 1 support audio output. When parsing audio, the multi-function card must connect to port 1 Maximum resolution 3840 x 1920 pixels. |
