P10 Outdoor Red Color LED Module 320x160mm

Outdoor DIP P10mm Single red color LED Display Module Size is 320mmx160mm With 32×16 dots.

P10 LED Panel Attention:

We recommend that you buy the same batch led modules at once for the Same LED Display.Because different batches of led modules have different brightness and display colors,even different config files.
If you want to build led screen,please buy enough LED Modules and Spare Parts.
Tariffs or Duties at the destination not included.If you have questions about Importation to your country,please contact us online sales.

P10 Outdoor Red Color LED Module 320×160 Main Specifications:

Model	LEEMAN-P10-Outdoor Single-32X16
Resolution	32(W) * 16(H)
Pitch	10 mm
LED Arrangement	DIP 346
Module Size	320mm×160mm
Driver Mode	Constant driving 1/4 scanning
Pixel color	Red/ Green/ Blue/Yellow/White
Electricity Parameter
Brightness	6500 – 6800 nits
View Angle	90-120(horizontal); 30-60(vertical)
View Distance	10 m -25m
Gray Scale	12ts input, correction with 16bits
Display Color	16.7M
Brightness Adjustment	100 levels
Density (Real) (dots/m^2)	10,000
Control mode	Asynchronous or Synchronous
Operation Power	AC100-240V 50-60HZ Switch-able
Maxim Power Consumption	15 W
Control System
Correction Scale Level	16bits
Frame Update Frequency	60Hz
Screen Refresh Frequency	≥1920HZ
Gamma Correction	-5.0~5.0
Reliability
Operating Temp.	-20-60 Celsius degree
Operating Humidity	10-95% RH
Operating Life	100,000 hours
MTBF	5000 hours
Continuous Working Time	≥48 hours
Protection Level	IP54
Out of Control Pixel Rate	0.01%
Protection	Semi-outdoor

High Quality LEDs:

High-Quality single color LED Display Module are equipped with data cables and power cables and 2 Years Warranty, All Outdoor LED panels with high brightness and color uniformity to ensure the LED display has excellent visual performance.

72+ Hours Aging

72 Hours aging test (white balance aging (2×24 hours) and video aging (24 hours)) to improve the reliability of the outdoor LED display panels.
