Pixel Pitch 1.953mm 2.604mm 2.976mm 3.91mm 4.81mm 5.95mm 6.25mm 8.33mm 10.41mm Aluminum Series Platinum Outdoor LED Display Screen DOOH Solution Rental Flexible Curved LED Screen P1.953 P2.604 P2.976 P3.91 P4.81 Nationstar Gold Wire IP66 IP68 Energy Saving Waterproof Outdoor LED Display 1000×500 and 1000×1000
$217.68 Original price was: $217.68.$199.00Current price is: $199.00.
1. Energy-Saving with Low Power Consumption
2. Ultra-Light and Thinness;
3. Simple Structure, Hard Link with Wireless;
4. High Protection Level, Security and Stability;
5. Easy to Realize Front and Rear Maintenance;
6. UL, EMC, CE, Rohs, ISO, FCC, IECEE, CB Certification
7. 5 Year Warranty and 10% Spare Part
SKU:
Leeman-P3.91-IP68-Outdood-Platinum-led-display-L1000xH500
Categories: IP66 Dual Service Energy Saving LED Screen
Share:
P1.953 P2.604 P2.976 P3.91 P4.81 Nationstar Gold Wire Energy Saving Waterproof Outdoor LED Display IP68
Platinum PRO Series IP68 Waterproof Outdoor LED Display Screen Solution
Dimension: 500*500*68mm
Pixel Pitch Indoor: (Mini LED 1.5mm, 1.9mm)2.6mm, 2.9mm, 3.9mm, 4.8mm
Pixel Pitch Outdoor: 1.9mm, 2.6mm, 2.9mm 3.9mm, 4.8mm
Applications: Concerts, Auto Show, Outdoor Stage Background, Expo, etc.
Key Features:
● High brightness 7000nits
● Magnetic panel system
● Strengthened corner protection
● Rigging & stacking installation
● Curving system achievable
● Easy maintenance
● Modular design
● Support 90° seamless splicing
● Hanging & Stacking installation
● Front & Rear maintenance
Platinum PRO Series High Brightness 7000nits Waterproof P1.9 P2.6 P2.9 P3.9 P4.8 Energy Saving Waterproof Outdoor LED Display IP68 Fixed Narrow Pixel LED Screen 500X1000 and 500×500 and 1000×1000
| Leeman Pro Series Outdoor Fixed Installation LED Display Screen 500×1000 And 500×500 | |||||
| Model NO. | P1.953 | P2.604 | P2.976 | P3.91 | P4.81 |
| Pixel Pitch | 1.95mm | 2.6mm | 2.9mm | 3.91mm | 4.81mm |
| LED Chip Lamp | NationStar Gold Wire | NationStar Gold Wire | NationStar Gold Wire | NationStar Gold Wire | NationStar Gold Wire |
| LED type | SMD1415 | SMD415 | SMD1921 | SMD1921 | SMD2525 |
| Flatness between modules | ≤ 0.1mm | ≤ 0.1mm | ≤ 0.1mm | ≤ 0.1mm | ≤ 0.1mm |
| Pixel configuration | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B |
| Module size (W*H) | 250*250mm | 250*250mm | 250*250mm | 250*250mm | 250*250mm |
| Module resolution (W*H) | 128*128mm | 96*96mm | 84*84mm | 64*64mm | 52*52mm |
| Cabinet size(W*H*D) | 500*1000*75mm | 500*1000*75mm | 500*1000*75mm | 500*1000*75mm | 500*1000*75mm |
| Cabinet resolution (W*H) | 256*512mm | 192*384mm | 168*336mm | 128*256mm | 104*208mm |
| Cabinet weight | 14.5kg/pc | 14.5kg/pc | 14.5kg/pc | 14.5kg/pc | 14.5kg/pc |
| Density | 262144dots/m² | 147456dots/m² | 112896dots/m² | 65400dots/m² | 43264dots/m² |
| IC | 2153 | 2153 | 2153 | 2153 | 2153 |
| Scan | 32S | 32S | 21S | 16S | 13S |
| Best viewing distance | >1.9m | >2.6m | >3m | >4m | >5m |
| Best viewing angle | 160°/ 120° | 160°/ 120° | 160°/ 120° | 160°/ 120° | 160°/ 120° |
| Brightness | 5500-6000cd/m² | 5500-6000cd/m² | 6000-6500cd/m² | 6000-6500cd/m² | 6500-7000cd/m² |
| Working voltage | AC：110-240V 50~60Hz | AC：110-240V 50~60Hz | AC：110-240 V 50~60Hz | AC：110-240V 50~60Hz | AC：110-240V 50~60Hz |
| Maximum power | ≤600W/ m² | ≤600W/ m² | ≤600W/ m² | ≤600W/ m² | ≤600W/ m² |
| Average power consumption | 100W/m² | 200W/m² | 200W/m² | 200W/m² | 200W/m² |
| ~300W / m² | ~300W / m² | ~300W / m² | ~300W / m² | ~300W / m² | |
| Screen temperature rise(running state) | ≤ 5 degrees | ≤ 5 degrees | ≤ 5 degrees | ≤ 5 degrees | ≤ 5 degrees |
| Operation of Environmental Temperature/°C | -10°C~60°C | -10°C~60°C | -10°C~60°C | -10°C~60°C | -10°C~60°C |
| Operating Temperature | 10%~90%RH | 10%~90%RH | 10%~90%RH | 10%~90%RH | 10%~90%RH |
| No condensation | No condensation | No condensation | No condensation | No condensation | |
| Screen color temperature | 2000K～9500K | 2000K～9500K | 2000K～9500K | 6500K～9500K | 7000K～10000K |
| Driving method | 1/32 scanning | 1/32 scanning | 1/32 scanning | 1/16 scanning | 1/16 scanning |
| Gray scale | 16 bits | 16 bits | 16 bits | 16 bits | 16 bits |
| Refresh frequency | ≥3840Hz | ≥3840Hz | ≥3840Hz | ≥3840Hz | ≥3840Hz |
| IP grade | Front:IP68 | Front:IP68 | Front:IP68 | Front:IP68 | Front:IP68 |
| Back:IP66 | Back:IP66 | Back:IP66 | Back:IP66 | Back:IP66 | |
| Continuous working time | ≥7×24hrs | ≥7×24hrs | ≥7×24hrs | ≥7×24hrs | ≥7×24hrs |
| Lifetime | 100,000hrs | 100,000hrs | 100,000hrs | 100,000hrs | 100,000hrs |
| Installation method | Back Frame Installation / Hoisting / Inner Arc Installation | ||||
| Pixel correction | Equipped with point – by – point brightness and chromaticity correction | ||||
| Control mode | Synchronization control | ||||
| Control distance | Super five double stranded network cable, more than 100 meters using optical fiber transmission | ||||
| Software interface | Windows XP /7/8/10 IOS | ||||
| Signal input | HDMI、DVI, VGA, USB, LAN（Extensible interface） | ||||
| Cabinet material | Waterproof Die-casting Aluminum | ||||
| PowerCon | Neutrick Power connector with cable | ||||
| EtherCon | Neutrick Power connection with cable | ||||
| Maintenance method | Dual Service, Front Maintenance and Back service | ||||
| Warranty time | 5 years warranty time and free lifetime technical support | ||||
| Certification | UL CE ETL ROHS EMC FCC ISO, IECEE, CB | ||||
