Novastar MRV206 LED Receiver Card LeemanLEDdisplay

Novastar MRV206 LED Receiver Card LeemanLEDdisplay Specification

Novastar MRV206 LED Receiver Card max support 256*256 pixels.

MRV206 is the new receiver card from Nova, single card max support 256 x 256 pixels.

It has the follow up features:

• Maximum load of 256 × 256 pixels
• Supports up to 12 sets of RGB parallel data.
• 6 standard HUB75 interfaces
• Support for lighting chromaticity correction
• Quickly bright and dark line adjustment on NovaLCT to eliminate
• 3D function- With independent masters that support 3D capabilities, at NovaLCT or Turn on the 3D function on the operator panel of the main control and set the 3D parameters.
• Loaded: − 192×256 (PWM IC); − 176×256 (General Purpose IC)
