Front Maintenance IP68 Outdoor LED Display With Nationstar SMD Gold Wire LED Chip P1.9 P2.6 P2.9 P3.9 P4.8
$395.27
Platinum Pro Series Outdoor Fixed Advertising LED Display Screen Solution
Dimension: 960*960*80mm
Pixel Pitch Outdoor: 3.3mm, 4mm, 5mm, 5.7mm, 6.67mm, 8mm, 10mm
Applications: DOOH Market, Billboard Advertisement, Road Sign, Stadiums, etc.
UL, EMC, CE, Rohs, ISO, FCC, CB, IECEE Approved
5 Years warranty time and 10% Spare Part
SKU:
Leeman-P3.91-Outdood-IP68-Platinum-led-display-Module-L500xH1000
Categories: IP68 Front Service Energy Saving LED Display
Share:
Front Maintenance IP68 Outdoor LED Display With Nationstar SMD Gold Wire LED Chip P1.9 P2.6 P2.9 P3.9 P4.8 LED Display Panel 1000x500mm and 500x500mm
Platinum Series Outdoor Fixed LED Display Screen Solution
Dimension: 500*1000*80mm
Pixel Pitch Outdoor: 1.9mm, 2.6mm, 2.9mm, 3.9mm, 4.8mm
Applications: Window Screen, Digital Signage System, Bus Station, Arena Display, Business Advertising Signs, Airport, etc.
Key Features:
● High brightness reach 7000nits
● Die-casting aluminum cabinet
● Front & rear service maintenance
● Fine pitch outdoor fixed installation
● IP68 and 5VB protection level
P1.953 P2.604 P2.976 P3.91 P4.81 Platinum PRO Series High Brightness 7000nits Waterproof Outdoor IP68 Fixed Narrow Pixel Front Maintenance IP68 Outdoor LED Display Module 500X1000mm and 500x500mm
| Leeman Pro Series Outdoor Fixed Installation LED Display Screen 500×1000 And 500×500 | |||||
| Model NO. | P1.953 | P2.604 | P2.976 | P3.91 | P4.81 |
| Pixel Pitch | 1.95mm | 2.6mm | 2.9mm | 3.91mm | 4.81mm |
| LED Chip Lamp | NationStar Gold Wire | NationStar Gold Wire | NationStar Gold Wire | NationStar Gold Wire | NationStar Gold Wire |
| LED type | SMD1415 | SMD415 | SMD1921 | SMD1921 | SMD2525 |
| Flatness between modules | ≤ 0.1mm | ≤ 0.1mm | ≤ 0.1mm | ≤ 0.1mm | ≤ 0.1mm |
| Pixel configuration | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B |
| Module size (W*H) | 250*250mm | 250*250mm | 250*250mm | 250*250mm | 250*250mm |
| Module resolution (W*H) | 128*128mm | 96*96mm | 84*84mm | 64*64mm | 52*52mm |
| Cabinet size(W*H*D) | 500*1000*75mm | 500*1000*75mm | 500*1000*75mm | 500*1000*75mm | 500*1000*75mm |
| Cabinet resolution (W*H) | 256*512mm | 192*384mm | 168*336mm | 128*256mm | 104*208mm |
| Cabinet weight | 14.5kg/pc | 14.5kg/pc | 14.5kg/pc | 14.5kg/pc | 14.5kg/pc |
| Density | 262144dots/m² | 147456dots/m² | 112896dots/m² | 65400dots/m² | 43264dots/m² |
| IC | 2153 | 2153 | 2153 | 2153 | 2153 |
| Scan | 32S | 32S | 21S | 16S | 13S |
| Best viewing distance | >1.9m | >2.6m | >3m | >4m | >5m |
| Best viewing angle | 160°/ 120° | 160°/ 120° | 160°/ 120° | 160°/ 120° | 160°/ 120° |
| Brightness | 5500-6000cd/m² | 5500-6000cd/m² | 6000-6500cd/m² | 6000-6500cd/m² | 6500-7000cd/m² |
| Working voltage | AC：110-240V 50~60Hz | AC：110-240V 50~60Hz | AC：110-240 V 50~60Hz | AC：110-240V 50~60Hz | AC：110-240V 50~60Hz |
| Maximum power | ≤600W/ m² | ≤600W/ m² | ≤600W/ m² | ≤600W/ m² | ≤600W/ m² |
| Average power consumption | 100W/m² | 200W/m² | 200W/m² | 200W/m² | 200W/m² |
| ~300W / m² | ~300W / m² | ~300W / m² | ~300W / m² | ~300W / m² | |
| Screen temperature rise(running state) | ≤ 5 degrees | ≤ 5 degrees | ≤ 5 degrees | ≤ 5 degrees | ≤ 5 degrees |
| Operation of Environmental Temperature/°C | -10°C~60°C | -10°C~60°C | -10°C~60°C | -10°C~60°C | -10°C~60°C |
| Operating Temperature | 10%~90%RH | 10%~90%RH | 10%~90%RH | 10%~90%RH | 10%~90%RH |
| No condensation | No condensation | No condensation | No condensation | No condensation | |
| Screen color temperature | 2000K～9500K | 2000K～9500K | 2000K～9500K | 6500K～9500K | 7000K～10000K |
| Driving method | 1/32 scanning | 1/32 scanning | 1/32 scanning | 1/16 scanning | 1/16 scanning |
| Gray scale | 16 bits | 16 bits | 16 bits | 16 bits | 16 bits |
| Refresh frequency | ≥3840Hz | ≥3840Hz | ≥3840Hz | ≥3840Hz | ≥3840Hz |
| IP grade | Front:IP68 | Front:IP68 | Front:IP68 | Front:IP68 | Front:IP68 |
| Back:IP66 | Back:IP66 | Back:IP66 | Back:IP66 | Back:IP66 | |
| Continuous working time | ≥7×24hrs | ≥7×24hrs | ≥7×24hrs | ≥7×24hrs | ≥7×24hrs |
| Lifetime | 100,000hrs | 100,000hrs | 100,000hrs | 100,000hrs | 100,000hrs |
| Installation method | Back Frame Installation / Hoisting / Inner Arc Installation | ||||
| Pixel correction | Equipped with point – by – point brightness and chromaticity correction | ||||
| Control mode | Synchronization control | ||||
| Control distance | Super five double stranded network cable, more than 100 meters using optical fiber transmission | ||||
| Software interface | Windows XP /7/8/10 IOS | ||||
| Signal input | HDMI、DVI, VGA, USB, LAN（Extensible interface） | ||||
| Cabinet material | Waterproof Die-casting Aluminum | ||||
| PowerCon | Neutrick Power connector with cable | ||||
| EtherCon | Neutrick Power connection with cable | ||||
| Maintenance method | Dual Service, Front Maintenance and Back service | ||||
| Warranty time | 5 years warranty time and free lifetime technical support | ||||
| Certification | UL CE ETL ROHS EMC FCC ISO, IECEE, CB | ||||
