Flexible LED Film Screen P6.25 Adhesive Transparent LED Film Display P4 P6.25 P8 P10 P15 P20
Product parameter table
Module size (mm) | 1000*400 | Peak power | 600w/㎡ |
LED light | NationStar SMD1515 | Average power | 200w/㎡ |
Pixel composition | R1G1B1 | Work environment | Temperature -20-55 Humidity10-90% |
Pixel spacing (mm) | 6.25*6.25 | Weight | 1.3kg |
Module pixel | 160*64=10240 | Thickness | 2.5mm |
Pixel/㎡ | 25600 | Drive mode | static state |
Brightness | 2000/4000 | Control system | Nova/Colorlight |
Permeability | 90% | Typical value of life | 100000H |
Angle of view ° | 160 | Grayscale level | 16bit |
input voltage | AC110-240V50/60Hz | Refresh rate | 3840Hz |
Breakpoint continuation
Stable performance, support two-way Drive drive-in LED,
When a single point of failure, the backup data signal starts automatically, seamless switching, without affecting the display effect.
Adhesive led transparent film screen High reliability
The fault lamp beads should be kept off. If the connection is abnormal (signal, power supply, ground) inside the chip, the lamp beads will be extinguished to avoid the phenomenon of steady on and random flashing.
The lamp bead life is more than 100,000 hours
High gray scale display (true 16bit)
RGB channel adopts 32-level current linear regulation, and maintains true 16-bit grayscale display under any current, which is applicable to the consistency of indoor,semi-outdoor and outdoor current requirements
No steel structure is required,just stick the thin screen slightly and connect the power signal
Self-developed glue filling process (the screen body with its own viscosity can be directly attached to the alass surface, with strong colloid adsorption, and the viscosity will also increase with the passage of time due to the inherent characteristics of the colloid)
Flexible transparent led film display screen High transmittance
Use the integrated MiniLED lamp beads to improve its own permeability
Use invisible grid circuit to improve its permeability
Patented products
Self-developed chip puts the chip inside the LED beads, simplifying the circuit design and ensuring extremely high permeability.
Transparent LED Film Screen Flexibility
Flexible design: Made of flexible materialsit can be flexibly bent and curved with a minimum diameter of 6cm.
adapting to various curved shapes, such as cylindrical, arc, etcthis gives greater flexibility in design and installation.
