Colorlight X16 Professional LED Wall Panel Controller Box

Original price was: $1,689.00.Current price is: $1,650.00.

X16 is a professional LED display controller. It possesses powerful video signal receiving, splicing and processing capacities, and supports multiple signal inputs, in which the maximum input resolution is [email protected]×2160 pixels. It supports digital ports (HDMI, DVI, SDI), and seamless switching between signals. It supports splicing, broadcast quality scaling, and seven-pictures displays.

or
SKU: Colorlight-X16 Categories:

Share:

X16 is a professional LED display controller. It possesses powerful video signal receiving, splicing and processing capacities, and supports multiple signal inputs, in which the maximum input resolution is ×2160 pixels. It supports digital ports (HDMI, DVI, SDI), and seamless switching between signals. It supports splicing, broadcast quality scaling, and seven-pictures displays.

Colorlight X16 Professional LED Wall Panel Controller Box



Colorlight X16 Professional LED Wall Panel Controller Box Parameter:

Input Interface
HDMI 2.0 HDMI 2.0 Input
EIA/CEA-861 Standard, in accordance with HDMI 2.0 standard, supports 4096×, supports HDCP
DVI 4 DVI inputs
VESA Standard (support 1920×, supports HDCP
SDI 2 SDI-3G inputs, 1920×1080P
Output Interface
Port1-16 RJ45, 16 Gigabit Ethernet outputs
Controlling Interface
LAN Network control (communication with PC, or access network)
USB_OUT USB output, cascading with the next controller
USB_IN USB input, which connects with PC to configure parameters
Genlock Genlock signal input ensures synchronism of display image
Genlock Loop Genlock synchronous signal loop output
4K Input Boards (Optional)
X16 (Standard) 1×HDMI 2.0 + 4×DVI
X16B (Customized) 8×DVI
X16C (Customized) 2×HDMI 2.0
Specifications
Size 2U standard box
Input voltage AC 100~240V
Rated Power Consumption 80W
Working Temperature -20~60℃

•Supports various digital signal ports, including 1×HDMI 2.0, 4×DVI, 2×SDI

•Supports input resolutions up to 4096×

•Loading capacity: 8.88 million, maximum width/height: 8192 pixels

•Supports arbitrary switching of video sources; the input images can be spliced and scaled according to the screen resolution

•Supports seven-pictures displays, the location and size can be adjusted freely

•Supports HDCP 2.2

•Dual USB2.0 for high speed configuration and easy cascading among controllers

•Supports brightness and chromaticity adjustments

•Supports improved gray-scale performance at low brightness

•Compatible with all receiving cards, multifunction cards, and optical fiber transceivers of Colorlight
