500×1000 LED Display Panel P3.91 Outdoor Rental Stage Led Screen Details
- 2 Years Warranty
- Magnesium Alloy
- Free tech guide
- 5% Spare Part, Power Supply, Receiver cards included.
- Lead time: 15-21 working days.
- Package：Flight Case
- Customized: If have special needs on size, lamps, IC or other requests, pls contact us.
| 500×1000 LED Display Panel P3.91 Outdoor Rental Stage Led Screen Specification | |||||||
| Indoor | Outdoor | ||||||
| Pixel pitch | 2.604mm | 2.976mm | 3.91mm | 4.81mm | 2.976mm | 3.91mm | 4.81mm |
| Pixels per cabinet (dots) | 192×192 | 168×168 | 128×128 | 104×104 | 168×168 | 128×128 | 104×104 |
| Module resolution (dots) | 96*96 | 84*84 | 64*64 | 52*52 | 84*84 | 64*64 | 52*52 |
| Avg Power consumption (W/m²) | 320 | 300 | 280 | 250 | 320 | 300 | 280 |
| Max Power consumption (W/m²) | 640 | 620 | 600 | 580 | 640 | 620 | 600 |
| Serviceability | Front and Rear service | Rear Service | |||||
| IP rating | IP54 | IP65 | |||||
| Brightness | ≥1000 nits; | ≥5500 nits; | |||||
| Module size | 250*250mm | ||||||
| Weight / Tile | 7.5 kg / 16.53 lbs | ||||||
| Dimensions | 500 x 1000 x 90 mm (WxHxD)/ 19.6 x 38.6 x 3.5 inch (WxHxD) |
||||||
| Refresh rate | 1,920-3,840Hz | ||||||
| Hor. viewing angle | 140° /-5° (@50% brightness) | ||||||
| Vert. viewing angle | 140° /-5° (@50% brightness) | ||||||
| Brightness uniformity | >98% | ||||||
| Dimming | 0-100% | ||||||
| Grey Level | 16 bits | ||||||
| Operation power voltage | 100-240V / 50-60Hz | ||||||
| Operational temperature | -10°C to 40°C / 14°F to 104°F | ||||||
| Operational humidity | 10-80% | ||||||
| LED lifetime | 100,000h (video – 50% brightness) | ||||||
| Certifications | CE, UL, FCC class A, RoHS, WEE, REACH | ||||||
| Warranty | 2 years | ||||||
