SSR-TEMP Temperature Humidity Sensor Colorlight LED Display Accessories is a high-precision temperature and humidity sensor with good-looking and small appearance, it is designed with standard guide rail structure and it has easy wire connection and simple installation.
SSR-TEMP adopts imported high-precision probe and ensures excellent measurement performance; it has high stability and anti-interference ability, it also has strong barrier property with first-class lightning protection.
Multiple modules can be connected to the bus network via RS485 interface to monitor multiple environmental conditions in real time.
Colorlight SSR-TEMP Temperature Humidity Sensor Accessories Features
·RS485 interface, communication distance up to 1200 meters;
·Imported probe, high precision, wide range, good consistency;
·Designed with standard guide rail structure, easy installation;
·High stability and anti-interference ability;
· Input voltage: DC5~12V;
·MODBUS RTU standard communication protocol;
·Strong barrier property, first-class lightning protection.
Specification | |
---|---|
Rated voltage | DC5V-12V |
Measuring range | Temperature:-40℃~120℃ Humidity:0~100%rh |
Measuring accuracy | Temperature: ±0.3℃ Resolution: 0.1℃ Humidity:±3%rh Resolution: 0.1rh |
Output interface | RS485 |
Communication protocol | MODBUS RTU |
Communication address | 1-247 |
Baud rate | 1200 bit/s,2400 bit/s, 4800 bit/s, 9600 bit/s, 19200 bit/s |
Average power consumption | <0.1W |
Wire length | 5 meters (standard) |
Installation | Guide rail mounting, walls mounting indoors, ceilings mounting |
FILE NAME | RELEASE NOTES | FILE SIZE | DOWNLOAD |
---|---|---|---|
SSR-Temperature and Humidity SensorSpecification | V1.1 | 239KB |
