NovaStar T60 Multimedia Card – Novastar taurus T60 multimedia card is the new choice for fixed installations in the intelligent cloud era.
NovaStar T60 Multimedia Card LED Screen Multimedia Player Controller, Easy intelligent control of displays, all in a slim form factor, taurus Series Multimedia Player is widely used in advertising, digital signage, and other commercial applications. Taurus is also effectively used in Smart Cities for pole screens, scientific community displays, colored public transportation displays, and more.
1. Safe and stable for worry-free operation:
1). Designed with safety in mind to keep troubles far away
2). Automatically connects to optimal signal, no longer a need to worry about signal loss
3). Comprehensive record of daily logs with full status monitoring
4). Real-time watchdog monitoring with automatic error correction
5). Receiving card cascading and redundant backup for multiple levels of protection
2. Flexible and unrestricted playback:
1). Cloud playback
2). Wireless playback
3). U-disk playback
4). Synchronized and asynchronous modes, to meet the needs of a variety of applications
5). Synchronized playback, with instant display to screen.
6). Asynchronous playback, with remote publishing, free switching between the two modes at any time
3. Synchronized playback:
1). Asynchronous playback
2). Control a large display with the same ease as you control your smartphone
3). No need for a PC – Effective control with just an APP
4). Pair with VNNOX cloud publishing for remote control of your display
5). Drastically lower cloud maintenance cost. More displays doesn’t mean greater cost
4. System allows manual maintenance and adjustment of display:
1). Difficulty to reach
2). High risk
3). Big cost
4). Professional integration, your new calibration partner
5). The entire Taurus Series features professional-level integrated calibration, to restore the display to it’s original beauty
5. Nova CLB point to point calibration system:
1). Color temperature and gamut adjustment
2). Adjustment of bright and dark seam lines
3). Calibration with and without a PC
4). One-button calibration
Model | TB30 | TB50 | TB60 | |
Basic Parameter | CPU | 4 Core A55 Processor/1.8GHz | 4 Core A55 Processor/1.8GHz | 4 Core A55 Processor/1.8GHz |
Storage | 1GB+16GB | 1GB+16GB | 1GB+16GB | |
Decode Ability | 4K 60fps | 4K 60fps | 4K 60fps | |
Operation system | Android 11 | Android 11 | Android 11 | |
Loading Capacity | Max Capacity | 0.65 million pixels | 1.3 million pixels | 2.3 million pixels |
Max Width/Max High | 4096(Max Width),4096(Max High) | 4096(Max Width),4096(Max High) | 4096(Max Width),4096(Max High) | |
LED Output port RJ45 | 1 Main 1 Backup | 2 Main | 4 Main | |
Main Function | Sync Mode | NTP,GPS | NTP,GPS | NTP,GPS |
Dual Mode Switch | / | Support | Support | |
Remotely Control Power | Need Connect Multifunction Card | Need Connect Multifunction Card | Need Connect Multifunction Card | |
Sensor | Two aviation plug | Two aviation plug | Two aviation plug | |
Network Communication | LAN | 1000 Mbps | 1000 Mbps | 1000 Mbps |
WiFi | 2.4G Switchable AP&STA | 2.4G Switchable AP&STA | 2.4G Switchable AP&STA | |
4G | Support(Option) | Support(Option) | Support(Option) | |
Appearance Material | Metal Case | Metal Case | Metal Case | |
Power Port | AC 100~240V | AC 100~240V | AC 100~240V | |
Certification | CE EMC、LVD、ROHS、FCC、FCC ID、 IC、RED、UKCA、UL、RCM、PSE、 FAC、PSB、KC、MIC、CB、NBTC |
CE EMC、LVD、ROHS、FCC、FCC ID、 IC、RED、UKCA、UL、RCM、PSE、 FAC、PSB、KC、MIC、CB、NBTC |
CE EMC、LVD、ROHS、FCC、FCC ID、 IC、RED、UKCA、UL、RCM、PSE、 FAC、PSB、KC、MIC、CB、NBTC |
TB30 | TB50 | TB60 | |
---|---|---|---|
Taurus Downloads |
Software Downloads |
|
Viplex Express/V2.13.0 | V-Can Handy/V3.6.0 |
