Colorlight C2 Media Player Cloud LED Control System can connect to Internet through LAN/WiFi/4G. Based on Colorlight Cloud Server.
ColorLight C2 Player can rapidly achieve unified management of multiple screens and multi-services across regions.
1.Interfaces
Colorlight C2 LED Media Player Controller Specification
Colorlight C2 Player LCD Screen Player WIFI 4G LED Player PC
2.Features
·Connect to Internet through LAN/WiFi/4G;
·Based on Colorlight Cloud Server, C2 can rapidly achieve unified management of multiple screens and multi-services across regions;
·Possessing powerful functions including equipment monitoring, program edition, scheduling and cluster publishing, multi-level authorization management, programs are published after review;;
·multiple play windows and windows overlap, size and location can be freely set;;
·C2 can be set as AP Mode, supports program management and parameters setting via smartphone, tablet, PC, etc;
·Supports GPS precise timing to achieve synchronization of multiple screens;
·C2 has many advantages in applications of LCD advertising screens and exhibition screens;
·8G build-in storage, 5G available for users; it supports USB storage, Plug&Play;
Basic Parameters | |
---|---|
Core Chips | 1.6GHz quad-core CPU; 600Mhz quad-core GPU; 1GB DDR3
1080P HD hardware decoding |
Interfaces | |
---|---|
Audio Output | 1/8×(3.5mm)TRS |
USB Ports | 2×USB2.0, supports external storage (U disc) or communication equipment |
HDMI Output | Output signal to LCD |
100M LAN | Access network |
WiFi | 2.4G/5G dual-band; supports AP mode and station mode |
4G (Option) | Access internet |
GPS (Option) | Precise positioning, precise timing, synchronization of multiple screens |
Physical Parameters | |
---|---|
Dimension | 205.4×107.5×23mm |
Working Voltage | DC 12V |
Rated Power | 10W |
Weight | 0.5kg |
Working Temperature | -25℃~80℃ |
Environmental Humidity | 0-95% without condensation |
File Format | |
---|---|
Program Split | Supports flexible program windows split, supports sflexible windows overlapping, supports multiple programs play |
Video Formats | Common formats such as AVI, WMV, MPG, RM/RMVB, MOV, DAT, VOB, MP4, FLV and etc.;
Supports multiple videos play at the same time |
Audio Formats | MPEG-1 Layer III,AAC etc. |
Image Formats | bmp, jpg, png, etc. |
Text Formats | txt, rtf, word, ppt, excel etc. |
Text Display | Single line text, static text, multiple line text, etc. |
Screen Split | 4 video windows, multiple picture/text windows, scrolling text, Logo, date/time/week. Flexible screen split can be achieved and different contents display in different area |
OSD Supported | Supports video/picture/text mixture or overlap with fully transparent, opaque, translucent effects |
RTC | Supports real time clock |
Terminal Management & Control | |
---|---|
Communication | LAN/WiFi/4G |
Program Update | Update program through USB or network |
Management Devices | Smart terminals like PC, Android, iOS and etc. |
Automatic Brightness Adjustment | Timing automatic adjustment; |
Timing Play | Play according to scheduled programs |
Software | LEDVISION 5.0 or higher vision |
FILE NAME | RELEASE NOTES | FILE SIZE | DOWNLOAD |
---|---|---|---|
C2 Specification | V1.0 | 344KB | |
C2 User Manual | V1.0 | 2.20MB |
